With Direct-to-Object printing with the Roland CO-i Series Models
Take object customization to new heights with the VersaOBJECT CO-i series of UV flatbed printers. Digital UV printing has never been more versatile and the CO-i series is the perfect solution for customizing boards or objects up to 9.5 inches (242 mm) in height and even irregular 3D objects.
- Premium-quality direct-to-object or substrate printing
- Special effect printing for added-value products
- High-volume object customization and personalization
- Available in a size and configuration to suit your business
- A new integrated control panel
VersaOBJECT CO-i Series
CO-640i-F3
$74,995
(98-in length, with vacuum)
Printable Width -63 inches
Printable Length Options – 98 inches
Max. Print Height – 9.5 inches
Bed Options – Flatbed with Vacuum
Available ink – CMYK, Gloss, White, Red, Orange, Primer
CO-300i-F2
$49,995 US
(60-in length, with vacuum)
Printable Width – 30 inches
Printable Length Options – 60 inches
Max. Print Height – 9.5 inches
Bed Options – Flatbed with Vacuum
Available ink – CMYK, Gloss, White, Red, Orange, Primer
The Ultimate in Versatile Print Production
Print high-quality, vibrant, impactful graphics directly onto a vast range of materials and objects, including metal, plastic, board, wood, canvas, vinyl, paper, and much more. Plus, CO-i series flatbeds can accommodate items up to 9.5 inches in height.
High Quality, Versatile Ink
Using the latest ECO-UV EUV5 inks for exceptional and premium-value printing, we go beyond CMYK to give you even more options and flexibility. Talk to a Roland DG product expert about your print requirements to discover the ink configuration that’s right for you.
Highlighted Features
Impressive Height and Weight Capabilities
Offering extraordinary application versatility, the CO-i series flatbeds can print on objects up to 9.5 inches in height and weigh up to 100 kg/m2 in weight.
New Integrated Control Panel
The control panel of the CO-i Series is integrated into the table to allow you to work more efficiently in less space. The more efficient design removes the conjoining cable trip hazard, reducing the possibility of damaging the device and increasing safety.
Print Large Quantities of Smaller Items
Improve your productivity with a fast and efficient direct-to-object printing solution. The CO-i series lets you print unique details on several items in a single print run. Plus, with VersaWorks 6 features like variable data printing, you can individually personalize each item quickly with minimal set-up.
Distance Mode
The CO-i series flatbed UV printers feature an innovative Distance Mode. This makes it possible to print onto convex, concave, or irregular surfaces while maintaining excellent quality and sharpness.
Low-Temperature Adjustable UV-LED Lamps
The intensity of the UV-LED lamps is adjustable from VersaWorks – they can be switched on, off, or set anywhere in between. This allows Gloss, Primer, and White to be used as an adhesive layer before a secondary process to apply glitter or foil and then cured with UV to seal.
Safety Control Features
An emergency stop perimeter around the base (and on the side of the device) safeguards operators in the busiest of production environments. For additional safety, there is a signal beacon with variable alerts that highlight the printer status.
Powerful Software Included
The VersaOBJECT CO-i series is even more powerful when paired with Roland DG’s advanced software solutions. Developed specifically for Roland DG, our easy-to-use, feature-filled software gives you all you need to produce your work, your way.
VersaWorks 6 RIP Software
Besides its high-speed RIP functionality, VersaWorks 6 RIP includes a wide selection of productivity-boosting features for the CO-i series, like automatic special color generation and variable data printing.
Roland DG Connect App
Reduce downtime and improve work efficiency with a machine monitoring assistant that gives you a clear picture of your print operation while running your device at optimum performance.
PrintAutoMate
This specialized software, an optional expansion to the Roland DG Connect app, lets you efficiently map print output onto objects in a printing jig, helping you automate your print workflow and streamline object customization.
Datasheet
Download Your CO-i Series Datasheet
Get your digital guide to all the features, applications, benefits and specifications of the UV Printers.
Specifications
| Model | CO-300i-F2 | CO-640i-F3 | |||
| Printing Method | Piezo ink-jet method | ||||
| Attachable objects to be printed on | Width | Max. 30 in. (762 mm ) | Max. 64 in. (1,625 mm) | ||
| Thickness | Max. 9.5 in. (242 mm) | ||||
| Weight | Max. 220.4 Ib (100 kg) | ||||
| Maximum Printing Width/Length | Max. 29.4 in. × 59.0 in. (749 × 1,500 mm) | Max. 63.4 in. × 98.4 in. (1,612 × 2,500 mm) | |||
| Ink | Types | ECO-UV（EUV5） 220 ml cartridge（White） ECO-UV（EUV5） 500 ml cartridge（Cyan, Magenta, Yellow, Black, Red, Orange, Gloss, Primer） | |||
| Colors | Eight colors (Cyan, Magenta, Yellow, Black, Red, Orange, White, Gloss) Seven colors (Cyan, Magenta, Yellow, Black, Red, Orange, White） Seven colors (Cyan, Magenta, Yellow, Black, Red, Orange, White) and Primer Seven colors (Cyan, Magenta, Yellow, Black, Red, White, Gloss) and Primer Six colors (Cyan, Magenta, Yellow, Black, White, Gloss) and Primer Six colors (Cyan, Magenta, Yellow, Black, White, Gloss） Four colors (Cyan, Magenta, Yellow, Black) | ||||
| Ink-curing unit | Built-in UV-LED lamp | ||||
| Printing resolution (dots per inch) | Max. 1,440 dpi | ||||
| Connectivity | Ethernet (100BASE-TX/1000BASE-T, automatic switching) | ||||
| Power-saving Function | Automatic sleep feature | ||||
| Power Requirements | 230V 16A 2P+E | ||||
| Power Consumption | During operation (100% Vacuum) | Approx. 1.80 kW | Approx. 2.90 kW | ||
| Sleep mode | Approx. 0.08 kW | ||||
| Acoustic Noise Level | During operation | 80 dB (A) or less | 90 dB (A) or less | ||
| During Standby | 70 dB (A) or less | 80 dB (A) or less | |||
| Dimensions (width x depth x height) | 76.0 in. × 93.9 in. × 57.9 in. (1,928 mm × 2,384 mm × 1,469 mm) | 110.9 in. × 133.9 in. × 57.9 in. (2,815 mm × 3,399 mm × 1,469 mm) | |||
| Weight | 1,074 lb. (487 kg) | 1,903 lb. (863 kg) | |||
| Environment | During operation(*1) | Temperature: 68 to 89.6 °F (20 to 32 °C), Humidity: 35 to 80 %RH (no condensation) | |||
| Not operating | Temperature: 41 to 104 °F (5 to 40 °C), Humidity: 20 to 80 %RH (no condensation) | ||||
| Included Items | Power cord, cleaning liquid, drain bottle, User’s Manual, software (VersaWorks, Roland DG Connect), etc. | ||||
